Common Materials

A short list of materials commonly handled with the ACS Material Handling Bucket :

  • Ashes
  • Cereals
  • Coal
  • Coke
  • Dirt/Rock Mix
  • Graveled Sand
  • Salt
  • Sand
  • Sawdust
  • Sugar
  • Wheat

Bolt-On Edge

Comes installed with beveled, wear-resistant steel edge that takes the brunt of all first-contact impacts. Double-sided for twice extended life; when one side wears down, simply turn it around to expose the fresh edge.

Heavy Wall Cross Tube

Heavy Wall Cross Tube

All ACS Excavator Buckets are built with Heavy Wall Cross Tube reinforcement across the top. This transfers breakout forces directly to the bucket cutting edge.

Specifications

Back to Top

Drainage Perforations

Provide fast escape routes for unwanted liquid in your payload.

Sizes

Excavator Size Cut Width Capacity Edge Weight
Class 10 60 1.2 Bolt-On Edge 1,148 lbs
Class 15 60 1.27 Bolt-On Edge 1,250 lbs
Class 20 72 1.80 Bolt-On Edge 1,925 lbs
Class 25 72 2.10 Bolt-On Edge 1,950 lbs
Class 30 72 2.75 Bolt-On Edge 2,740 lbs
Class 30 72 3.25 Bolt-On Edge 3,210 lbs

Get a Quote for this Attachment

Attachments available as direct-pin or quick coupler adapted. ACS will respond with pricing and current availability for this attachment.
